48v 60Ah LiFePO4 Cathode Battery Pack In Customized Size

LIFEPO4 is the more efficient technology batteries , knocking out traditional lead acidbatteries . VODNO provides a complete line of 12 ,24 and 48 volt batteries for use inRVS , Boats , Evs and off-grid applications and much more.

Quantity:
Share this:

Electric bicycle

Electric motorcycle

Electric tricycle

Electric boat

Motorhome

Energy storage

RC toy

Led light

Street light

UPS

Medical Equipment

Robot

Overview

Battery System

Our 48v battery system supports solar energy storage of both commercial and industrial purposes,The system is built from intergration of Basic

storage of Basic storage battery in parallel connection with BMS (Battery Management System)for protection and communication.

Standard lineup

1.Operating voltage 48v and 51.2V

2.Typical Basic Battery 48V 100Ah while more option from 48v 10Ah/20Ah/30Ah/50Ah/70Ah

3.Optional capacity in cabinet size 200Ah~600Ah

Features

1.Multiple of basic storage battery of nominal voltage 48v in parallel connection

2.Each basic storage battery with built in intelligent BMS effectively prevent battery overcharge,over-discharge,overcurrent and over-temperaure.

3.Standard 19 inch rack-mount durable enclosure for plug & play replacement.

4.Equipped with RS485/RS232 communication

5.Standard BMS with options for charging current limit in parallel connection (programmable ON/OFF)

6.Efficient & long-lasting service life

Custom manufacturing

1.Custom battery system is available through intergration of more basic storage battery.

2.Battery systems of different operating voltage,capacity etc.

Specifications

Model

VDO4860

General Characteristics

Nominal voltage

51.2V(16S)

Nominal capacity@0.2C

60Ah

Mini. capacity@0.2C

58Ah

Nominal energy

3.07KWh

Dimensions(W*D*H)

360*290*180mm (customzied)

Approx. weight(exclude cabinet)

24.5Kgs

Battery connection

16S10P

Electrical Characteristics





Operating voltage range

51.2V

Recommended charging voltage

58.4V

Max. charging current

40A

Max.continuous discharge current

40A

Max.peak discharge current

80A,<3S

Discharging cut-off voltage

40v

Faraday charging efficiency

≥98%

Energy charging efficiency

≥92%

Operating conditions



Operating temperature

Charge

0℃~55℃

Discharge

-20℃~60℃

Storage temperature

0℃~55℃

Storage duration

12Months @20℃~25℃

Water dust resistance

Plastic shrinking packing

Lifecycle times

2000 at 90% DOD

Application

The energy storage battery is applicable for commercial or residential purposes.

1.Solar Energy Storage  2.Solar Street lighting  3.Light Electric Vehicle  4.E-bike/E-Rickshaw  5.Golf Cart  6.UPS

About Us

Vodno Technology Co., Ltd. was founded in 2010, the predecessor of the lithium material, electric bike battery, and the core production-based manufacturers, after nearly seven years of development, has developed into a product design and development, battery solutions and electronic circuit program Design, battery production and quality control, sales in one of the high-tech Co., Ltd., and become the battery industry's leading enterprises. Vodno take a senior engineer of the engineering and technical team as the core,after the years of practice summed up a set of highly efficient and accurate design standards and production management practices to ensurethat each design, each product is uncompromising attention to excellence. "Treat every client with sincerity, implement every promise" is Vodno's corporate culture, scientific management, rigorous attitude, high-quality elite to Vodno brought rapid growth, won the recognition of overseas customers around the world.Now, Vodno Technology Co., Ltd. has more than 20 countries and regions around the world with a number of well-known enterprises to cooperate, many of them like "Foxconn" the world's top 500 enterprises, and most products have been CE, ROHS, UN, etc. International Standard Certification. Today, Vodno has grown into a trusted gold supplier in the battery industry.

FAQ

Q1. How to proceed an order for Battery?


A1: Firstly, pls let us know your requirements,such as the dimension,continuous&peak discharge current ,application of the battery.
Secondly,pls let us know the purchasing quantity and when will your project start.We quote according to the details.
Thirdly customer confirms the price,sample and places deposit for formal order.
Fourthly We arrange the production.

Q2: How to deal with the faulty?

A2: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new batteries with new order to replace the defective.
Thirdly,we will test the defective batteries and make 8D report.We will find out the reason and propose the
improvement measures for future production.

Q3: Do you support door to door shipping? drop ship ?

A3: Yes. If battery unit weight is below 30kg, we can delivery it via Air Express. If battery unit weight is above 30kg, we delivery it via sea. If you want to us to help you to make custom clearance, we would like to do that. We support drop ship.

Q4 Does your battery include BMS? Can we use it for vehicle?

A4.:Yes, our battery pack include BMS, you can use it for low speed vehicles.And make sure the discharge current can meet the application request. If you want to use standard vehicle, please inform us, we need to adopt more complex design BMS and different technology solution.
