Lithium battery professional builder
Also UPS can comes with a built-in inverter, enabling seamless DC-to-AC power conversion without an external inverter module. It provides stable AC backup power for loads during mains failure.
Electric bicycle
Electric motorcycle
Electric tricycle
Electric boat
Motorhome
Energy storage
RC toy
Led light
Street light
UPS
Medical Equipment
Robot
Long cycle lifespan, stable performance for long-term backup power supply
· Built-in pure sine wave inverter, all-in-one design, simplify installation and wiring
· Wide operating temperature range, adaptable to harsh industrial environments
· Excellent safety performance with multiple protection circuits (OVP/UVP/OTP/SCP)
· Low self-discharge rate, long standby time
· Maintenance-free design, reduce later operation cost
· High energy density, compact size, save installation space
· Supports continuous DC-AC conversion, seamless switch when power outage
· Compatible with medical equipment, server room, CCTV surveillance, industrial instruments.
|
Manufacturer |
Shenzhen VODNO Technology Co. Ltd |
|
|
Model |
VDO-i500W-B300WH |
|
|
Power input |
Voltage |
AC110V, 50Hz/60Hz |
|
Input power |
≤500VA |
|
|
Charge Voltage |
DC 29.2V |
|
|
Charge Power |
≤300W |
|
|
Power output |
AC |
AC110V, 50Hz/60Hz (Pure Sine Wave) |
|
≤300W |
||
|
DC |
DC12V 24W |
|
|
DC24V 30W |
||
|
Display screen |
1.44 inch |
|
|
Communication protocol |
RS 485 |
|
|
Cooling method |
Air cooling by fan |
|
|
Work temp. |
-10℃～45℃ |
|
|
Dimension |
L*W*H≤312×218×90mm |
|
|
Weight |
Appr. 6.1kg |
|
Inverter Specification
|
Power input |
Input power |
≤500VA |
|
Voltage |
AC100V～AC120V |
|
|
Frequency |
50Hz/60Hz±0.5Hz |
|
|
Current |
≤5A ac |
|
|
Charge Voltage |
DC 29.2V±0.5V |
|
|
Charge Power |
≤ 300W |
|
|
Power output |
Voltage |
AC110V±10% |
|
Frequency |
50Hz/60Hz±0.5Hz |
|
|
Wave form |
Pure Sine Wave |
|
|
Output Power |
≤300W |
|
|
Max. efficiency |
90% |
|
|
Switching time |
≤15ms |
|
|
Protect function |
Over voltage / Low voltage / Over load / Short circuit / Over hot / Reverse polarity |
|
|
Work Temp |
-20℃～45℃ |
|
Battery Specification
|
Battery type |
LiFePO4 |
|
Rated voltage |
25.6V |
|
Rated capacity |
12AH |
|
Minimum capacity |
≥11AH |
|
Charge voltage |
≤29.4V |
|
Charge current |
≤20A |
|
Discharge cut-off voltage |
20V±3V |
|
Discharge current |
≤20A |
|
Protect function |
Over voltage / Low voltage / Over load / Short circuit / Over hot / Reverse polarity |
|
Communication Protocol |
RS 485 |
|
Cycle life |
1500 cycles |
Medical-Grade Safety
Excellent thermal stability; low risk of fire and explosion. Non-toxic materials, no acid leakage, suitable for ward and operating room environments.
Millisecond Seamless Switchover
Instant power switching during mains failure, avoiding shutdown of life-support and precision medical equipment. Stable voltage output for sensitive medical electronics.
Ultra-Long Service Life
2000–3000 charge-discharge cycles, service lifespan up to 5–8 years. Greatly cuts replacement frequency and total operation cost compared with VRLA batteries.
High Efficiency & Wide Temperature Adaptability
＞95% charge-discharge efficiency; reliable performance from -20℃ to +55℃, ideal for ambulances and mobile medical carts.
Lightweight & Compact + Maintenance-Free
30%~50% lighter than lead-acid batteries of equal capacity. Sealed structure, no regular water topping-up required.
Customizable Solution
Multiple voltage & capacity options; support CAN/RS485 communication for remote monitoring. Rack-mounted, wall-mounted and portable configurations available.
