Customized Lifepo4 72v 26Ah Lithium Battery For E-motorcycle/EV/Golf Cart/Rickshaw/scooter

LIFEPO4 is the more efficient technology batteries , knocking out traditional lead acid batteries . VODNO provides a complete line of 12 ,24 and 48 volt batteries for use inRVS , Boats , Evs and off-grid applications and much more.

Quantity:
Share this:

Electric bicycle

Electric motorcycle

Electric tricycle

Electric boat

Motorhome

Energy storage

RC toy

Led light

Street light

UPS

Medical Equipment

Robot

Overview

lithium batteries provide up to 10 times longer life than lead-acid batteries, and they still provide 80% of rated capacity after 2,000 cycles. Most lithium-ion batteries last five years or more. The average lead-acid battery lasts just two years. Lead-acid batteries also need to be maintained, requiring water replacement to avoid structural damage; if they aren’t maintained properly, their life span is shortened even further. Because lithium batteries require no active maintenance, a one-time purchase guarantees longevity.



 How to make a decision for difference of battery materail

Specifications

Model

VDO7226

General Characteristics

Nominal voltage

76.8V

Nominal capacity@0.2C

26Ah

Min. capacity@0.2C

25Ah

Nominal energy

1996.8Wh

Dimensions(W*D*H)

270*230*170mm

Approx. weight(exclude cabinet)

18Kg

Battery connection

24S4P

Electrical Characteristics









Operating voltage range

60V~87.6V

Recommended charging voltage

87.6V

Max. charging current

20A

Max.continuous discharge current

30A

Max.peak discharge current

60A,<3S

Discharging cut-off voltage

60v

Faraday charging efficiency

≥98%

Energy charging efficiency

≥92%

Operating conditions







Operating temperature

Charge

0℃~60℃

Discharge

-20℃~60℃

Storage temperature

-10℃~60℃

Storage duration

12Months @20℃~25℃

Water dust resistance

IP30

Lifecycle times

2000 at 80% DOD

Application

The energy storage battery is applicable for commercial or residential purposes.

1.Solar Energy Storage  2.Solar Street lighting  3.Light Electric Vehicle  4.E-bike/E-Rickshaw  5.Golf Cart  6.UPS

What is Your Application?Talk to us, Vodno Battery Experts will offer you a best solution
