Deep Lifecycle Lifepo4 Lithium Battery 24v 100ah For Boat

LiFePO4 is the more efficient technology batteries, knocking out traditional lead acid batteries . VODNO provides a complete line of 12, 24 and 48 volt batteries for use in RV’s, Boats, EV's and off-grid applications and much more.

Quantity:
Share this:

Electric bicycle

Electric motorcycle

Electric tricycle

Electric boat

Motorhome

Energy storage

RC toy

Led light

Street light

UPS

Medical Equipment

Robot

Overview

lithium batteries provide up to 10 times longer life than lead-acid batteries, and they still provide 80% of rated capacity after 2,000 cycles. Most lithium-ion batteries last five years or more. The average lead-acid battery lasts just two years. Lead-acid batteries also need to be maintained, requiring water replacement to avoid structural damage; if they aren’t maintained properly, their life span is shortened even further. Because lithium batteries require no active maintenance, a one-time purchase guarantees longevity.



 How to make a decision for difference of battery materail





Specifications

Model

VDO-LF24100

General Characteristics

Nominal voltage

25.6V

Nominal capacity@0.2C

100Ah

Nominal energy

2.56kWh

Internal Resistance

45≦mΩ

Life cycle

>2000Cycles @0.2C Charging /Discharging at 90%DOD

Self-Discharge

≤3.5%per month at 25℃

Standard Charging









Charging voltage

29.2+/-0.2V

Charging Mode(CC/CV)

At 0℃~45℃temperature, charged to 29.2V at constant current 0.2C5A,and then at constant voltage 29.2V until the current drops to 0.02C5A

Charging Current

20A

Max.Charging Current

50A

Standard Discharging









Discharging Current

50A

Max.Continuous Current

100A

Max.Pulse Current

200A(<3S)

Discharging cut-off Voltage

20.0V

Operating conditions







Operating temperature

Charge

0℃~45℃

Discharge

-20℃~60℃

Storage temperature

0℃~45℃

Water dust resistance

IP56

Structure

Casing

ABS

Dimension

522*238*218*220mm

Approx.Weight

27kgs

Terminal

M8

Application

The energy storage battery is applicable for commercial or residential purposes.

1.Solar Energy Storage  2.Solar Street lighting  3.Light Electric Vehicle  4.E-bike/E-Rickshaw  5.Golf Cart  6.UPS

About Us

Vodno Technology Co., Ltd. was founded in 2010, the predecessor of the lithium material, electric bike battery, and the core production-based manufacturers, after nearly seven years of development, has developed into a product design and development, battery solutions and electronic circuit program Design, battery production and quality control, sales in one of the high-tech Co., Ltd., and become the battery industry's leading enterprises. Vodno take a senior engineer of the engineering and technical team as the core,after the years of practice summed up a set of highly efficient and accurate design standards and production management practices to ensurethat each design, each product is uncompromising attention to excellence. "Treat every client with sincerity, implement every promise" is Vodno's corporate culture, scientific management, rigorous attitude, high-quality elite to Vodno brought rapid growth, won the recognition of overseas customers around the world.Now, Vodno Technology Co., Ltd. has more than 20 countries and regions around the world with a number of well-known enterprises to cooperate, many of them like "Foxconn" the world's top 500 enterprises, and most products have been CE, ROHS, UN, etc. International Standard Certification. Today, Vodno has grown into a trusted gold supplier in the battery industry.

FAQ

Q1. How to proceed an order for Battery?


A1: Firstly, pls let us know your requirements,such as the dimension,continuous&peak discharge current ,application of the battery.
Secondly,pls let us know the purchasing quantity and when will your project start.We quote according to the details.
Thirdly customer confirms the price,sample and places deposit for formal order.
Fourthly We arrange the production.

Q2: How to deal with the faulty?

A2: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new batteries with new order to replace the defective.
Thirdly,we will test the defective batteries and make 8D report.We will find out the reason and propose the
improvement measures for future production.

Q3: Do you support door to door shipping? drop ship ?

A3: Yes. If battery unit weight is below 30kg, we can delivery it via Air Express. If battery unit weight is above 30kg, we delivery it via sea. If you want to us to help you to make custom clearance, we would like to do that. We support drop ship.

Q4 Does your battery include BMS? Can we use it for vehicle?

A4.:Yes, our battery pack include BMS, you can use it for low speed vehicles.And make sure the discharge current can meet the application request. If you want to use standard vehicle, please inform us, we need to adopt more complex design BMS and different technology solution.

What is Your Application?Talk to us, Vodno Battery Experts will offer you a best solution
