HEAT Pro Series Lifepo4 Battery 12v 100Ah Perfectly Adapted For Motorhome

LiFePO4 is the more efficient technology batteries, knocking out traditional lead acid batteries . VODNO provides a complete line of 12, 24 and 48 volt batteries for use in RV’s, Boats, EV's and off-grid applications and much more.

Quantity:

Overview

The battery has built-in Bluetooth that gives a complete overview of the condition, consumption and temperature etc. The batteries in the HEAT Pro series have built-in heating foil that protects the battery at minus degrees so that it can be used and recharged throughout the year.
Bluetooth app can be loaded down by the look on smart BMS (AppStore or Google Play)
At minus degrees, the built-in heat film will activate and temper the battery before charging. The heat film is activated by a charging source and does not draw power from the battery during charging or consumption.

Specifications

Model		VDO-LF12100
General Characteristics
Nominal voltage		12.8V
Nominal capacity@0.2C		100Ah
Nominal energy		1280Wh
Internal Resistance		35≦mΩ
Life cycle		>2000Cycles @0.2C Charging /Discharging at 90%DOD
Self-Discharge		≤3.5%per month at 25℃
Standard Charging
Charging voltage		14.6+/-0.2V
Charging Mode(CC/CV)		At 0℃~45℃temperature, charged to 14.6V at constant current 0.2C5A，and then at constant voltage 14.6V until the current drops to 0.02C5A
Charging Current		40A
Max.Charging Current		150A
Standard Discharging
Discharging Current		40A
Max.Continuous Current		150A
Max.Pulse Current		300A（<3S)
Discharging cut-off Voltage		10.0V
Operating conditions
Operating temperature	Charge	0℃～45℃
	Discharge	－20℃～60℃
Storage temperature		0℃～45℃
Water dust resistance		IP56
Structure
Casing		ABS
Dimension		398175188mm
Approx.Weight		13kgs
Terminal		M8

Application

Lithium’s lifepo4 Batteries include Bluetooth Battery Monitoring with the bluetooth App, heating function. Upgraded Cells and a more smart BMS. Available in a 120Ah Starting Battery, 100Ah and 60Ah batteries. 12v batteries are capable of series and parallel connections!
