Lithium Iron Phosphate Lifepo4 Batteries 12v 12ah Renewable Energy

Lithium Iron Phosphate Lifepo4 Batteries 12v 12ah Renewable Energy

LiFePO4 is the more efficient technology batteries, knocking out traditional lead acid batteries . VODNO provides a complete line of 12, 24 and 48 volt batteries for use in RV’s, Boats, EV's and off-grid applications and much more.

Quantity:

Overview

Compared to lead-acid and other lithium batteries, lithium iron phosphate batteries offer significant advantages, including improved discharge and charge efficiency, longer life span and the ability to deep cycle while maintaining power. LiFePO4 batteries often come with a higher price tag, but a much better cost over life of the product. No maintenance and super long life makes them a worthwhile investment and a smart long-term solution.

Specifications

Model		VDO-LF1212
General Characteristics
Nominal voltage		12.8V
Nominal capacity@0.2C		12Ah
Nominal energy		153.6Wh
Internal Resistance		70≦mΩ
Life cycle		>2000Cycles @0.2C Charging /Discharging at 80%DOD
Self-Discharge		≤3.5%per month at 25℃
Standard Charging
Charging voltage		14.6+/-0.2V
Charging Mode(CC/CV)		At 0℃~45℃temperature, charged to 14.6V at constant current 0.2C5A，and then at constant voltage 14.6V until the current drops to 0.02C5A
Charging Current		2.4A
Max.Charging Current		6A
Standard Discharging
Discharging Current		2.4A
Max.Continuous Current		12A
Max.Pulse Current		30A（<3S)
Discharging cut-off Voltage		10.0V
Operating conditions
Operating temperature	Charge	0℃～45℃
	Discharge	－20℃～60℃
Storage temperature		0℃～45℃
Water dust resistance		IP56
Structure
Casing		ABS
Dimension		1516595mm
Approx.Weight		1.55kgs
Terminal		Wires/Connector （customized）
